1 Layer FR4 PCB Production Record #FR4-20260514-019
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| PCB Type | FR4 PCB | Quantity | 5 pcs |
| Layers | 1 Layers | Board Type | Single PCB |
| Dimensions | 52.07 x 64.77 mm | Copper Weight | 1oz |
| Thickness | 1.6 mm | Min Track / Spacing | 10/10mil |
| Surface Finish | HASL Lead Free | Min Hole Size | 0.8mm↑ |
| Solder Mask | Green | Silkscreen | White |
| Stack-up | Default | Impedance Control | No |
This order consisted of five single-sided 1-layer FR4 PCBs measuring 52.07 × 64.77 mm with standard 1.6 mm thickness and 1 oz copper weight. The design called for 10/10 mil minimum track and spacing together with 0.8 mm minimum hole size, both well within conventional fabrication ranges. Green solder mask, white silkscreen, and HASL Lead Free surface finish completed the requirements for this small prototype quantity.
Engineering review and material preparation were followed by circuit imaging and etching on the single side. Solder mask application preceded molten solder coating and hot air leveling to form the HASL Lead Free finish. The default stackup required no special impedance considerations, allowing the process to proceed directly from etching through to final coating.
Electrical testing confirmed continuity on every board before shipment. Production of the complete order took 1.6 days, yielding five functional boards that matched all specified parameters.
This order also received positive feedback from the customer regarding the consistent quality and reliable delivery. View the full customer review→
Single-sided FR4 boards form the foundation for numerous electronic products. We provide an optimal balance of cost, reliability, and manufacturability for diverse applications.
Discover the most common engineering queries (EQ) in 1 layer FR4 PCB production, from hole plating confusion to solder mask mismatches. Learn practical file preparation tips to minimize delays and speed up approval.
