High Layer Count FR4 PCB Production Record #FR4-20260709-064

Start FR4 PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type FR4 PCB Quantity 1500 pcs
Layers 12 Layers Board Type Single PCB
Dimensions 58 x 24.9 mm Copper Weight 1oz
Thickness 3 mm Min Track / Spacing 6/6mil↑
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.3mm↑
Solder Mask Green Silkscreen White
Stack-up Custom Impedance Control No

Manufacturing Timeline

Order Created
Jun 15 11:50
Files Ready
Jun 15 11:50
Engineering Review Completed
Jun 15 12:05
Payment down
Jun 17 10:07
Production Started
Jun 17 10:11
Production Completed
Jul 04 14:02
Progress: 0/6
Engineering Review time: 0.2 h
Production time: 17.2d

Logistics Information

Production Completed→Shipping : 5.2d
Carrier
UPS
Destination
KOREA, REPUBLIC OF (SOUTH K.)
Shipping Method
Express Air
Shipping Time
Jul 09 16:41

Key Manufacturing Processes

01
Engineering Review
02
Material Preparation
03
Inner Layer Imaging
04
Circuit Imaging & Etching
05
Layer Stack Alignment
06
High Pressure Lamination
07
Solder Mask Application
08
Electroless Nickel Deposition
09
Immersion Gold Deposition
10
Panelization Optimization
11
Batch AOI Inspection
12
Yield Control Management
13
Electrical Testing

Manufacturing Summary

For this order we produced 1500 units of 12-layer FR4 boards with a finished thickness of 3.0 mm and a custom stackup. The compact 58 × 24.9 mm boards used 1 oz copper and standard 6/6 mil geometry, with all holes at or above 0.3 mm. During inner layer imaging, circuit etching, and high-pressure lamination we maintained tight registration to accommodate the increased layer count and board thickness, ensuring flatness and interlayer alignment without blind vias or impedance requirements.



Green soldermask and white silkscreen were applied prior to electroless nickel and immersion gold deposition, delivering a uniform ENIG surface finish suited to the design. Each production panel received AOI after solder mask and full electrical testing at completion, verifying continuity across the 12 layers. The absence of advanced features allowed the process to focus on plating consistency and dimensional stability for the thicker multilayer construction.



Completed over 17.2 days, the run yielded boards that met every specified parameter. Material preparation through final inspection supported repeatable quality, confirming reliable via formation and layer bonding for this specific 12-layer configuration.
