8 Layer HDI PCB Production Record #HDI-20260715-0002

Start HDI PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type HDI PCB Quantity 840 pcs
Layers 8 Layers Board Type Panel PCB
Dimensions 152.5 x 114 mm Copper Weight 2oz
Thickness 1.8 mm Min Track / Spacing 6/6mil↑
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.2mm
Solder Mask Blue Silkscreen White
HDI Structure 3 Blind/Buried Vias Yes

Manufacturing Timeline

Order Created
May 12 16:40
Files Ready
May 12 16:40
Engineering Review Completed
May 12 16:50
Payment down
May 12 16:50
Production Started
May 13 16:59
Production Completed
Jun 04 17:13
Progress: 0/6
Engineering Review time: 10 min
Production time: 22.1d

Logistics Information

Production Completed→Shipping : 0.9d
Carrier
UPS
Destination
HONG KONG,CHINA
Shipping Method
Express Air
Shipping Time
Jun 05 14:25

Key Manufacturing Processes

01
Engineering Review
02
Material Preparation
03
Inner Layer Imaging
04
Circuit Imaging & Etching
05
Layer Stack Alignment
06
High Pressure Lamination
07
Sequential Lamination
08
Laser Microvia Drilling
09
Via Filling & Plating
10
Thick Copper Electroplating
11
Controlled Copper Etching
12
Solder Mask Application
13
Electroless Nickel Deposition
14
Immersion Gold Deposition
15
Panelization Optimization
16
Batch AOI Inspection
17
Yield Control Management
18
Electrical Testing

Manufacturing Summary

This order involved the manufacture of 840 panels of 8-layer HDI PCB, each sized 152.5 x 114 mm with a board thickness of 1.8 mm and 2oz copper. The build employed a custom stackup incorporating blind vias in a 3-step HDI configuration. With minimum trace width and spacing at 6 mil and hole sizes down to 0.2 mm, the boards received blue soldermask, white silkscreen, and an immersion gold ENIG surface finish.



Execution required sequential lamination processes, precision laser drilling for the microvias, followed by via filling, plating, and controlled etching to accommodate the thicker copper. These steps demanded careful management to achieve reliable interlayer connections without compromising the finer geometries.



Over the course of 62 days, the production maintained strict process controls. Comprehensive batch AOI inspection and electrical testing at completion confirmed high consistency across the entire quantity, delivering panels that met all specified parameters for the customer's project.
