PCB Specifications
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| PCB Type | HDI PCB | Quantity | 125 pcs |
| Layers | 8 Layers | Board Type | Panel PCB |
| Dimensions | 188 x 100 mm | Copper Weight | 1oz |
| Thickness | 1.6 mm | Min Track / Spacing | 5/5mil |
| Surface Finish | ENIG (Immersion Gold) | Min Hole Size | 0.15mm |
| Solder Mask | Matte Black | Silkscreen | White |
| HDI Structure | 3 | Blind/Buried Vias | Yes |
Manufacturing Timeline
Logistics Information
Key Manufacturing Processes
Manufacturing Summary
This 8-layer HDI circuit board order consisted of 125 panels, each 188 by 100 mm with 1.6 mm thickness and 1 oz copper weight. The 3-step HDI configuration with blind vias required sequential lamination and laser microvia drilling to realize the 0.15 mm minimum hole size alongside 5/5 mil track and spacing. These tighter geometries called for specialized handling in the circuit imaging and etching phases to ensure trace integrity.
We prepared the custom stackup materials and executed high-pressure lamination with strict attention to registration. Following via filling and plating, matte black soldermask was applied with white silkscreen legend. The boards then received immersion gold ENIG surface finish through electroless nickel deposition and gold immersion, providing a flat, reliable contact surface.
Electrical testing verified continuity and isolation across the full production run, confirming the build met all specified parameters for this HDI design. The completed panels reflect consistent manufacturing execution suitable for high-density applications.
