High Layer Count FR4 PCB Production Record #FR4-20260522-050

Start FR4 PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type FR4 PCB Quantity 10 pcs
Layers 10 Layers Board Type Panel PCB
Dimensions 323.6 x 323.6 mm Copper Weight 2oz
Thickness 1.6 mm Min Track / Spacing 6/6mil↑
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.3mm↑
Solder Mask Green Silkscreen White
Stack-up Custom Impedance Control No

Manufacturing Timeline

Order Created
Apr 22 11:25
Files Ready
Apr 22 11:25
Engineering Review Completed
Apr 22 11:51
Payment down
Apr 26 06:11
Production Started
Apr 26 06:15
Production Completed
May 20 16:32
Progress: 0/6
Engineering Review time: 7 min
Production time: 24.5d With Engineering Questions

Logistics Information

Production Completed→Shipping : 2.0d
Carrier
DHL
Destination
UNITED STATES OF AMERICA
Shipping Method
Express Air
Shipping Time
May 22 15:31

Key Manufacturing Processes

01
Engineering Review
02
Material Preparation
03
Inner Layer Imaging
04
Circuit Imaging & Etching
05
Layer Stack Alignment
06
High Pressure Lamination
07
Thick Copper Electroplating
08
Controlled Copper Etching
09
Solder Mask Application
10
Electroless Nickel Deposition
11
Immersion Gold Deposition
12
Electrical Testing

Manufacturing Summary

This order comprised ten 323.6 × 323.6 mm 10-layer FR4 panels built on a custom stackup with 2 oz copper weight and 1.6 mm finished thickness. Material preparation and high-pressure lamination received close attention to maintain layer registration across the large panel format, while thick copper electroplating and controlled etching preserved the standard 6/6 mil trace and spacing without undercutting or bridging. The absence of blind vias and impedance control allowed conventional drilling of 0.3 mm minimum holes and straightforward via filling prior to outer-layer processing.



Green solder mask and white silkscreen were applied before electroless nickel deposition and immersion gold plating, producing a flat ENIG surface finish that supports consistent solder joint formation. Every panel completed full electrical testing to confirm net continuity and isolation. The 24.5-day production window accommodated the sequential processes from engineering review through final inspection, delivering uniform boards that met all dimensional and plating requirements.
