PCB Specifications
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| PCB Type | FR4 PCB | Quantity | 5 pcs |
| Layers | 2 Layers | Board Type | Single PCB |
| Dimensions | 185 x 245 mm | Copper Weight | 2oz |
| Thickness | 1.6 mm | Min Track / Spacing | 6/6mil↑ |
| Surface Finish | HASL Lead Free | Min Hole Size | 0.5mm |
| Solder Mask | Green | Silkscreen | White |
| Stack-up | Default | Impedance Control | No |
Manufacturing Timeline
Logistics Information
Key Manufacturing Processes
Manufacturing Summary
This production record covers five units of 2-layer FR4 PCBs, each with dimensions of 185 x 245 mm, 1.6 mm board thickness, and 2 oz copper weight on both layers. The heavier copper on this conventional 6/6 mil geometry required thick copper electroplating and controlled copper etching to maintain accurate trace profiles and reliable plating in the 0.5 mm holes without compromising edge definition.
After circuit imaging, green solder mask and white silkscreen were applied, followed by molten solder coating and hot air leveling to produce a uniform HASL Lead Free surface. With default stackup and no impedance control specified, the process sequence remained straightforward yet demanded close attention to copper distribution across the relatively large board size and limited five-piece quantity.
Electrical testing confirmed full continuity and isolation on every board. The complete cycle from engineering review to final inspection was completed in 1.4 days, delivering boards that met all specified parameters for this 2 oz copper configuration.
This order also received positive feedback from the customer regarding the consistent quality and reliable delivery. View the full customer review→
Explore More PCB Manufacturing Resources
2 Layer FR4 PCB Manufacturing Insights
2 layer FR4 PCBs deliver cost-effective solutions for most electronic designs. Their simple structure enables consistent quality and efficient production cycles.
Why 1 Layer and 2 Layer FR4 PCB Trigger Frequent Engineering Queries in Production
Real Engineering Queries (EQ) and DFM issues for 2 Layer FR4 PCB (double-sided boards) from actual production reviews. Learn how to avoid common problems with via treatment, silkscreen on pads, solder mask openings, hole attributes, board edge clearance, and other frequent design pitfalls.
