HASL Aluminum PCB Production Record #ALU-20250915-0046
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| PCB Type | Aluminum PCB | Quantity | 500 pcs |
| Layers | 1 Layers | Board Type | Panel PCB |
| Dimensions | 18.01 x 750 mm | Copper Weight | 1oz |
| Thickness | 0.8 mm | Min Track / Spacing | 10/10mil |
| Surface Finish | HASL Lead Free | Min Hole Size | 1.5mm↑ |
| Solder Mask | High Reflectivity White | Silkscreen | Black |
| Thermal Conductivity | 1.0W | Voltage Withstand | AC3000V |
These aluminum PCBs were produced as 500 panels in a single-layer configuration, featuring dimensions of 18.01 x 750 mm and 0.8 mm thickness. With 1.0W thermal conductivity, the manufacturing sequence emphasized metal base preparation and thermal insulation lamination to secure dielectric integrity for the AC3000V withstand requirement. The long panel format demanded precise handling to maintain uniformity during processing.
Standard 10/10 mil track spacing on 1oz copper allowed straightforward imaging and etching. High reflectivity white soldermask combined with black silkscreen delivered the optical performance needed, followed by HASL Lead Free surface finish via molten solder coating and hot air leveling. This approach ensured excellent solderability without compromising the board's thermal pathways.
Over the 5.7-day production cycle, integrated heat dissipation control, AOI inspection, and electrical testing verified consistency across the batch. The executed processes resulted in reliable aluminum PCBs meeting all specified electrical and thermal parameters.
