PCB Specifications
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| PCB Type | FR4 PCB | Quantity | 10 pcs |
| Layers | 1 Layers | Board Type | Panel PCB |
| Dimensions | 176 x 135 mm | Copper Weight | 1oz |
| Thickness | 1.6 mm | Min Track / Spacing | 6/6mil↑ |
| Surface Finish | HASL Lead Free | Min Hole Size | 0.3mm↑ |
| Solder Mask | Green | Silkscreen | White |
| Stack-up | Custom | Impedance Control | No |
Manufacturing Timeline
Logistics Information
Key Manufacturing Processes
Manufacturing Summary
This production record covered 10 single-sided FR4 Panel PCBs measuring 176 × 135 mm with 1.6 mm thickness and 1 oz copper. The design used standard 6/6 mil track and spacing together with 0.3 mm minimum hole size, eliminating the need for impedance control and allowing conventional single-layer processing parameters. Material preparation and engineering review confirmed that the custom stackup matched the required single-sided configuration exactly, so all downstream steps could proceed without deviation.
Circuit imaging and etching defined the copper pattern on the FR4 substrate before green solder mask and white silkscreen were applied. Lead-free HASL surface finish was achieved through molten solder coating followed by hot air leveling, producing a flat, uniform coating suited for reliable through-hole and SMT assembly. Every panel then completed full electrical testing to verify net continuity and isolation.
The entire sequence from material cut to final inspection took 1.8 days and delivered panels that met all dimensional and electrical criteria without rework. Consistent solder mask registration and leveling height across the batch supported straightforward downstream assembly for the customer.
This order also received positive feedback from the customer regarding the consistent quality and reliable delivery. View the full customer review→
