High Layer Count FR4 PCB Production Record #FR4-20260330-021

Start FR4 PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type FR4 PCB Quantity 100 pcs
Layers 10 Layers Board Type Panel PCB
Dimensions 170 x 110 mm Copper Weight 1oz
Thickness 1.6 mm Min Track / Spacing 4/4mil
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.2mm
Solder Mask Matte Black Silkscreen White
Stack-up Custom Impedance Control Yes

Manufacturing Timeline

Order Created
Jan 14 16:01
Files Ready
Jan 14 16:01
Engineering Review Completed
Jan 14 16:48
Payment down
Feb 06 22:33
Production Started
Feb 09 15:34
Production Completed
Mar 05 23:10
Progress: 0/6
Engineering Review time: 0.8 h
Production time: 24.4d

Logistics Information

Production Completed→Shipping : 2.6d
Carrier
UPS
Destination
UNITED STATES OF AMERICA
Shipping Method
Express Air
Shipping Time
Mar 07 11:26

Key Manufacturing Processes

01
Engineering Review
02
Stackup Impedance Engineering
03
Trace Width Compensation
04
Material Preparation
05
Inner Layer Imaging
06
Circuit Imaging & Etching
07
Layer Stack Alignment
08
High Pressure Lamination
09
Solder Mask Application
10
Electroless Nickel Deposition
11
Immersion Gold Deposition
12
TDR Impedance Testing
13
Electrical Testing

Manufacturing Summary

For this production record, we manufactured 100 panels of 10-layer FR4 PCBs featuring a custom stackup, impedance control, and 4/4 mil trace width and spacing. The panels measure 170 x 110 mm with 1.6 mm thickness and 1 oz copper weight, incorporating a 0.2 mm minimum hole size. During fabrication, we completed detailed stackup impedance engineering, applied trace width compensation during inner layer imaging and etching, then executed precise layer stack alignment and high-pressure lamination to maintain registration across the multilayer construction.



Matte black soldermask with white silkscreen and immersion gold ENIG surface finish were applied after solder mask processing. We performed electroless nickel deposition and immersion gold deposition, followed by TDR impedance testing on the impedance controlled PCB to verify the custom stackup parameters. All 100 panels then completed electrical testing with no rework required, confirming uniform electrical and physical properties throughout the batch.



The full sequence from material preparation through final testing took 24.4 days and delivered panels that met every specified tolerance for this tighter-geometry multilayer design. This execution reflects consistent process control for impedance controlled PCBs that require both fine features and reliable signal integrity.

Real Production Records

Order ID PCB Type Layers Dimensions Solder Mask Surface Finish Quantity Action
FR4-20260819-043 FR4 PCB 10 157 x 140 Blue ENIG (Immersion Gold) 100 View detail
FR4-20260818-014 FR4 PCB 2 110.32 x 173.3 Green ENIG (Immersion Gold) 200 View detail
FR4-20260811-033 FR4 PCB 8 226.8 x 109 Green ENIG (Immersion Gold) 50 View detail
