High Layer Count FR4 PCB Production Record #FR4-20260715-027

Start FR4 PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type FR4 PCB Quantity 5 pcs
Layers 10 Layers Board Type Panel PCB
Dimensions 95 x 62.37 mm Copper Weight 1oz
Thickness 1.6 mm Min Track / Spacing 3/3mil
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.15mm
Solder Mask Green Silkscreen White
Stack-up Custom Impedance Control Yes

Manufacturing Timeline

Order Created
Jan 30 03:03
Files Ready
Jan 30 03:03
Engineering Review Completed
Jan 30 03:53
Payment down
Apr 30 11:41
Production Started
May 14 15:27
Production Completed
May 27 18:28
Progress: 0/6
Engineering Review time: 0.4 h Multiple File Revisions
Production time: 13.2d With Engineering Questions

Logistics Information

Production Completed→Shipping : 1.7d
Carrier
FedEx IP
Destination
BRAZIL
Shipping Method
Express Air
Shipping Time
May 29 09:16

Key Manufacturing Processes

01
Engineering Review
02
Stackup Impedance Engineering
03
Trace Width Compensation
04
Material Preparation
05
Inner Layer Imaging
06
Circuit Imaging & Etching
07
Layer Stack Alignment
08
High Pressure Lamination
09
Solder Mask Application
10
Electroless Nickel Deposition
11
Immersion Gold Deposition
12
TDR Impedance Testing
13
Electrical Testing

Manufacturing Summary

This production record covers five units of a 10-layer impedance controlled PCB built on FR4 material in panel format. The boards measure 95 x 62.37 mm with a finished thickness of 1.6 mm and 1 oz copper throughout the custom stackup. Key challenges included the tight 3/3 mil trace and spacing geometry combined with a 0.15 mm minimum hole size, requiring precise process controls during inner layer imaging, etching, and high pressure lamination.



Green soldermask with white silkscreen was applied before the immersion gold ENIG surface finish was deposited. TDR impedance testing confirmed that all controlled lines met target values, while comprehensive electrical testing verified continuity and isolation across each panel. Layer stack alignment received close attention given the multilayer complexity and panel configuration.



The manufacturing sequence concluded in 13.2 days, producing boards that exhibited consistent quality and fully satisfied every specified parameter of this advanced 10-layer design.
