8 Layer HDI PCB Production Record #HDI-20260729-036

Start HDI PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type HDI PCB Quantity 100 pcs
Layers 8 Layers Board Type Panel PCB
Dimensions 97 x 93.4 mm Copper Weight 3oz
Thickness 1.6 mm Min Track / Spacing 5/5mil
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.25mm
Solder Mask Black Silkscreen White
HDI Structure 3 Blind/Buried Vias Yes

Manufacturing Timeline

Order Created
Jun 03 20:57
Files Ready
Jun 03 20:57
Engineering Review Completed
Jun 03 21:44
Payment down
Jun 05 16:01
Production Started
Jun 05 16:03
Production Completed
Jun 29 13:56
Progress: 0/6
Engineering Review time: 0.8 h Multiple File Revisions
Production time: 24.0d With Engineering Questions

Logistics Information

Production Completed→Shipping : 0.6 h
Carrier
DHL
Destination
NETHERLANDS, THE
Shipping Method
Express Air
Shipping Time
Jun 29 14:30

Key Manufacturing Processes

01
Engineering Review
02
Material Preparation
03
Inner Layer Imaging
04
Circuit Imaging & Etching
05
Layer Stack Alignment
06
High Pressure Lamination
07
Sequential Lamination
08
Laser Microvia Drilling
09
Via Filling & Plating
10
Thick Copper Electroplating
11
Controlled Copper Etching
12
Solder Mask Application
13
Electroless Nickel Deposition
14
Immersion Gold Deposition
15
Electrical Testing

Manufacturing Summary

For this order, we produced 100 panels of 8-layer HDI PCBs that incorporate blind vias using a 3-step HDI structure. The dimensions are 97 x 93.4 mm with 1.6 mm thickness and 3 oz copper weight. Given the tighter 5/5 mil track spacing and 0.25 mm min hole size, the manufacturing sequence included inner layer imaging, sequential lamination, laser microvia drilling, via filling and plating, as well as thick copper electroplating and controlled copper etching.



The custom stackup was prepared with careful layer alignment before high pressure lamination. We then applied black soldermask and white silkscreen, followed by immersion gold ENIG surface finish through electroless nickel deposition and gold immersion.



These steps addressed the specific demands of combining heavier copper layers with fine HDI geometries. Comprehensive electrical testing verified the quality and consistency across all panels, confirming successful execution of this HDI PCB order.
