6 Layer HDI PCB Production Record #HDI-20251022-0008

Start HDI PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type HDI PCB Quantity 5 pcs
Layers 6 Layers Board Type Panel PCB
Dimensions 58 x 116 mm Copper Weight 1oz
Thickness 1 mm Min Track / Spacing 3/3mil
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.15mm
Solder Mask Blue Silkscreen White
HDI Structure 2 Blind/Buried Vias Yes

Manufacturing Timeline

Order Created
Sep 22 08:40
Files Ready
Sep 22 08:40
Engineering Review Completed
Sep 22 09:39
Payment down
Sep 26 18:18
Production Started
Sep 26 18:22
Production Completed
Oct 20 19:32
Progress: 0/6
Engineering Review time: 1h
Production time: 24.1d

Logistics Information

Production Completed→Shipping : 1.7d
Carrier
FedEx IP
Destination
ISRAEL
Shipping Method
Express Air
Shipping Time
Oct 22 11:19

Key Manufacturing Processes

01
Engineering Review
02
Material Preparation
03
Inner Layer Imaging
04
Circuit Imaging & Etching
05
Layer Stack Alignment
06
High Pressure Lamination
07
Sequential Lamination
08
Laser Microvia Drilling
09
Via Filling & Plating
10
Solder Mask Application
11
Electroless Nickel Deposition
12
Immersion Gold Deposition
13
Electrical Testing

Manufacturing Summary

This production record covers five 6-layer HDI PCBs built as panels measuring 58 by 116 mm with 1.0 mm thickness and 1 oz copper. The design specified 3/3 mil trace and spacing, blind vias, and a 2-step HDI structure. Sequential lamination, laser microvia drilling, and via filling with plating were executed to maintain precise layer registration and interconnect reliability on this tighter geometry.



Blue soldermask and white silkscreen preceded immersion gold ENIG surface finish, selected for its flat topography and long-term solderability. Material preparation, inner layer imaging, circuit etching, and high-pressure lamination followed parameters matched to the 0.15 mm minimum hole size. Electrical testing confirmed continuity across all five panels without impedance control requirements.



The completed HDI PCBs showed consistent via plating and surface quality, delivering dependable boards suited to compact electronics applications.

Real Production Records

Order ID PCB Type Layers Dimensions Solder Mask Surface Finish Quantity Action
HDI-20260729-036 HDI PCB 8 97 x 93.4 Black ENIG (Immersion Gold) 100 View detail
HDI-20260720-0001 HDI PCB 8 188 x 100 Matte Black ENIG (Immersion Gold) 125 View detail
HDI-20260718-0002 HDI PCB 4 37 x 26.6 Green ENIG (Immersion Gold) 20 View detail
