8 Layer HDI PCB Production Record #HDI-20260113-0023

Start HDI PCB Quote

PCB Specifications

Parameter Value Parameter Value
PCB Type HDI PCB Quantity 500 pcs
Layers 8 Layers Board Type Panel PCB
Dimensions 152.5 x 114 mm Copper Weight 2oz
Thickness 1.8 mm Min Track / Spacing 6/6mil↑
Surface Finish ENIG (Immersion Gold) Min Hole Size 0.2mm
Solder Mask Blue Silkscreen White
HDI Structure 3 Blind/Buried Vias Yes

Manufacturing Timeline

Order Created
Dec 17 16:07
Files Ready
Dec 17 16:07
Engineering Review Completed
Dec 17 16:16
Payment down
Dec 17 18:20
Production Started
Dec 17 18:20
Production Completed
Jan 12 16:52
Progress: 0/6
Engineering Review time: 10 min
Production time: 26.0d

Logistics Information

Production Completed→Shipping : 0.9d
Carrier
UPS
Destination
HONG KONG,CHINA
Shipping Method
Express Air
Shipping Time
Jan 13 13:59

Key Manufacturing Processes

01
Engineering Review
02
Material Preparation
03
Inner Layer Imaging
04
Circuit Imaging & Etching
05
Layer Stack Alignment
06
High Pressure Lamination
07
Sequential Lamination
08
Laser Microvia Drilling
09
Via Filling & Plating
10
Thick Copper Electroplating
11
Controlled Copper Etching
12
Solder Mask Application
13
Electroless Nickel Deposition
14
Immersion Gold Deposition
15
Panelization Optimization
16
Batch AOI Inspection
17
Yield Control Management
18
Electrical Testing

Manufacturing Summary

Production of this 8-layer HDI PCB order centered on a three-stage build with blind vias, executed through sequential lamination and laser microvia drilling. The panels, sized at 152.5 x 114 mm, incorporated 2 oz copper on a 1.8 mm finished thickness. Via filling and plating steps were completed prior to controlled copper etching to achieve the required circuit definition at 6/6 mil geometry.



Blue soldermask and white silkscreen were applied over the immersion gold ENIG surface finish, selected for its compatibility with the board's high-density interconnects and long-term reliability. The 0.2 mm minimum hole size integrated well with the overall HDI configuration.



Across the 500-panel run, which spanned 26 days, engineering review, inner layer imaging, and batch electrical testing ensured all parameters stayed within specification. The resulting boards demonstrate stable performance consistent with the documented processes.
