OSP Aluminum PCB Production Record #ALU-20240801-0041
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| PCB Type | Aluminum PCB | Quantity | 5 pcs |
| Layers | 1 Layers | Board Type | Panel PCB |
| Dimensions | 210 x 605.5 mm | Copper Weight | 1oz |
| Thickness | 1.6 mm | Min Track / Spacing | 10/10mil |
| Surface Finish | OSP | Min Hole Size | 1.5mm↑ |
| Solder Mask | White | Silkscreen | Black |
| Thermal Conductivity | 3.0W | Voltage Withstand | AC3000V |
This production record details five single-layer aluminum PCBs in panel format, each measuring 210 x 605.5 mm with 1.6 mm overall thickness. The aluminum base provides 3.0W thermal conductivity paired with 1 oz copper traces at a conventional 10/10 mil geometry. Additional characteristics include white soldermask, black silkscreen, OSP surface finish, 1.5 mm minimum hole size, and AC3000V voltage withstand, making these panels well-suited for applications requiring both electrical insulation and efficient heat dissipation.
Manufacturing began with material preparation and metal base preparation, followed by thermal insulation lamination to bond the layers effectively. Circuit imaging and etching formed the circuitry, then solder mask application, organic coating for the OSP finish, and anti-oxidation treatment were executed. Heat dissipation control remained a priority to preserve the aluminum PCB's thermal properties throughout the 12.1-day production schedule.
Comprehensive electrical testing confirmed that all panels met the specified requirements with consistent results. This execution delivered reliable aluminum PCBs focused on the thermal and structural demands of the customer's design.
Discover how AIVON manufactures OSP Aluminum PCBs, including aluminum substrate structures, copper surface protection, thermal management considerations, manufacturing challenges, and real production experience from customer orders.
Choosing between a double layer al pcb hasl finish and OSP? Our pcb cam team reveals how to avoid critical engineering queries and manufacturing defects. Learn to optimize your pcb manufacturing process for better heat dissipation and assembly reliability today.
